BT1-A031R / T1-60G - Steimel United States Sales

BRAND	Steimel
Product	BT1-A031R / T1-60G
Internal code	ONR4625873
Custom code	84136039
Technical specification	pump free shaft ATEX gear pump PTFE, GD, EC, AW, G3/4, M37GN/10+K+R, preb.f.KL (YBX469), GGK shaft Gear pumps: T1-60G according to Directive 2014/34/EU (ATEX) Item number: BT1-A031R Dimension sheet: DPP001-A031R Spare parts list (pump only): DET001-A031R Operating instructions: DBA-ZP02 + DBA-ZP-ATEX-01 Suction and discharge connection: G ¾ Material finish: Housing parts: EN-GJL-250 (EN-JL 1040) Drive and counter pinion: 16 MnCrs 5, hardened straight-toothed Shaft seal: mechanical seal M 37 GN/10+K+R Q12Q1KGG1 Elastomers of the mechanical seal: Kalrez temperature monitoring on the mechanical seals: prepared for1 PTC thermistor Display device: on-site Bearing Bushings: Bronze AW increased bearing clearance: without Case seal: Loctite other elastomers: PTFE Extraction hole: without Pumped medium: paints and varnishes solvent-based, pigment-containing, max. 100 μm grain size Concentration: 10 - 70% Viscosity: 1,000 - 2,000 mm2/s Temperature: max. 70 degrees C rinsing with solvent (viscosity 30 - 1000 mm2/s) approx. 10% of the passage of time Delivery data: Q: 0 - 300 L/h p: 0 - 3 bar (pump must suck) n: 0 - 250 rpm direction of rotation: right Test run: yes, with HLPD 46 Pre-cleaning: rinse with mineral spirits Paint: RAL 5009 (HDE) Silicone-free pump! The pump was tested with mineral oil and must be flushed on site before commissioning! Sign: EAY924-PL02 Identification plate: ETY924-D-E—PE03 ATEX marking: II 2G Ex h IIB T3 Gb X Please observe the provisions of Directive 2014/34/EU (ATEX) regarding the use of our pumps in hazardous areas. Prerequisite for operation according to: Ex zone 1 (gas), temperature class T 3, Ambient temperature -20 to 40°C Explosion group IIB. Attention: Before starting the pump, the temperature monitoring can be connected functionally!

Please Contact Us to Order to offer competitive prices and delivery time for Steimel - BT1-A031R / T1-60G number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
