BRAND | Steimel |
Product | ATF4-70RD-170192R |
Internal code | ONR4179089 |
Custom code | 84136039 |
Technical specification | A-TF4-70RDG-GKM, Pump unit 4.0kW, 1500, 230/400V, 50Hz, IP55, F, Tropical Isolated, IE3 Gear pump unit: TF 4-70 RDG - GKM Product No.። ATF4-70RD-170192R Dimension sheet: DPA004F-170192R Spare parts list: DET004F-070RD051R Suction and pressure connection: DN 40, PN 25 Housing Parts: EN-GJL-250 (GG-25) Waves: 16mnCRS5, Egh. Gears: EN-GJS-400-15 (GGG-40), helical, ionised Shaft sealing: radial shaft seal Elastomers: NBR Storage: Multilayer MD Pumped medium: lubricating oil Temperature: 10-60°C Viscosity: 50-5000 cSt Flow rate: approx. 109/130 l/min. Pressure: 2 - 3 bar Speed: 1450/1740 RPM Pressure Relief Valve Opening pressure: 5 bar Setting range: 1-8 bar Direction of rotation: right Base Plate: EGP913060-24BB01 Clutch: BKUP096-2028-001 Engine documentation: EUL—020180BB01 Clutch protection: BKS918132170BA60 3-phase motor: LDM112-04-071 (Siemens) Engine data: Power 1/2:4,0/4,6 kW Speed 1/2:1500/ 1800 rpm. Voltage/frequency 1:230/400 volts at 50 Hz Voltage/frequency 2:460 volts - star at 60 Hz Efficiency class: IE3 with additional plate (B07) (without IE 3) for Voltage/Frequency: 220-240/380-420 V @50 hz 440-480 V @60 Hz Degree of protection: IP 55 Insulation class: F Special feature: Tropical protection for 100% humidity at 40°C (N21) Design: B 3 Painting: primer Seevenax Topcoat RAL5015 (HDE5015) Layer thickness 2 x 40-60 μm) Total layer thickness 220 -260 μm Identification plate: ETY924-D-E—PE02 weight 100 kg. |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ATF4-70RD-170192R number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
