BRAND | Steimel |
Product | SF 4/80 RD - LF (PSF4-80RD-151439R) |
Description | P-SF4/80RD-LF, Gear pump |
Internal code | ONR4204846 |
Technical specification | FKM, suitable for NEMA 215 TD (similar to B5) Gear pump: SF 4/80 RD - LF Product no.: PSF4-80RD-151439R Dimension sheet: DPP054D-151439R Spare parts list: DET054080RD—165R Suction and pressure connection: SAE 2 Housing Parts: EN-GJL-250 (GG-25) Waves: 16 Mn Cr S 5, Egh. Ionitated Gears: EN.GJS-400-15 (GGG-40) helical Storage: Multilayer Shaft sealing: radial shaft seal Elastomers: FKM Pumped medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 104/124 l/min. Pressure: 5 bar Speed: 1450/1740 RPM Pressure Relief Valve Setting range: 2-16 bar Opening pressure: 8 bar Direction of rotation: right Trial: yes, with HLPD 46 Clutch: BKUA065-2434-302 Pump carrier with foot: BLF054285165LA01 suitable for NEMA engine: Fiz/ Type: NEMA - 215 TD, without foot Paint: primed Identification plate: ETY924-D-E—PE01 Engine Mounting Screw: 4 pcs IBO1/2X31A2, loose in Pump carrier screwed in |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - SF 4/80 RD - LF (PSF4-80RD-151439R) P-SF4/80RD-LF, Gear pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
