BRAND | Leser |
Product | 4592.2482 |
Description | Compact Performance Safety Valve |
Internal code | ONR4278469 |
Custom code | 84814010 |
Technical specification | Type 459, closed spring cap, gas-tight cap H2, for vapors, gases and liquids Order code output, line 1: K7RMB1K4XH03M09K3IP2AJ99X00V10 Order code output, line 2: V18L49MA9MA2MA8MA6H01N68 Medium: Liquids liquids E-body material: 1.4404/316L 1.4404/316L Fl.Connection Entrance: (V10) NPS 1" Cl 300/600 according to ASME B16.5 Fl.Connection exit: (V18) NPS 1" Cl 150 according to ASME B16.5 Nominal inlet NPS 1" Nominal outlet NPS 1" Pressure level inlet 600 lbs pressure level outlet 150 lbs d0 (ASME-DIN) [mm] 13.0 Response pressure: 550.00 Printing unit: psi-g Response pressure [bar-g] 37.92 Response pressure in psi-g: 550.00 cold adjustment pressure [bar-g] 37.92 cold setting pressure [psi-g] 550.00 Operating temperature: 68 Temperature unit: °F - Fahrenheit Operating temperature [°C] 20.00 Operating temperature in °F: 68 Plate, metal/ Wst.: (L49) Made of material: 1.4122 Sealing ring material: (MB1) Sealing ring made of graphite/1.4401 Pressure Bolt Material: (K7R) Pressure screw material: 1.4104 Spring bonnet material: (J99) Spring bonnet material 1.0619/ WCB/ WCC Spring material (X00) Standard material Colorway: (P2A) 1-layer coating system in RAL 5005 according to LID 1608.03 Material quality certificate for: (H01) Housing # Position 1 with Material Quality Certification 3.1 according to DIN EN 10204 Delivery Specification: (N68) Approval according to ASME Sec. VIII, Div. 1 (UV Stamp) Documentation: (H03) LESER CGA Certificate for Global Application Acceptance Test Certificate 3.1 according to DIN EN 10204 Print setting: (M09) with water Tag-no., Valve 1:14105-SPCL Type and location of day no.: (M25) Labelling with tag (foil/paper) Flow rate D/G: 0.81 Flow rate F: 0.53 |
Please Contact Us to Order to offer competitive prices and delivery time for Leser - 4592.2482 Compact Performance Safety Valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
