4415.7382 - H2 - Leser United States Sales

BRAND	Leser
Product	4415.7382 - H2
Description	High performance safety valve
Internal code	ONR4832625
Custom code	84814010
Technical specification	Type 441 DIN, closed spring cover, gas tight cap H2, for vapors, gases and liquids Technical specification: Order code output, line 1: K7TK5RM33MB1K4ZH03K3IJ78P2AJ36 Order code output, line 2: X00H88H84H51H47H23L8KL64J59J21 Order code output, line 3: (H01) Case material: (H23) 0.7043 (GGG40.3) Nominal diameter inlet DN 25 Nominal diameter outlet DN 40 d0 (ASME-DIN) [mm] 23.0 Outflow rate D/G: 0.70 Outflow rate F: 0.45 Inlet flange pressure stage (H47) PN 40 in accordance with DIN EN 1092 Outlet flange pressure stage (H51) PN 16 in accordance with DIN EN 1092 Inlet flange sealing surface: (H84) Form B1 (rough) in accordance with DIN EN 1092 Outlet flange sealing surface: (H88) Form B1 (rough) in accordance with DIN EN 1092 Response pressure: 16.00 Pressure unit: bar-g Response pressure [bar-g] 16.00 Response pressure in psi-g: 232.06 Cold set pressure [bar-g] 16.00 Cold setting pressure [psi-g] 232.06 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Plate, metallic/Wst.: (J59) Made of material: 1.4104/ 430F Soft sealing plate: (J21) with CR “K” soft seal Seal material: (MB1) Graphite sealing ring/1.4401 Bellows: (J78) Counterpressure-compensating bellows, material: stainless steel 1.4571 /316Ti, Spring cover with open control connection Spring cover material: (J36) 0.7043 (GGG 40.3) Spring material (X00) standard material Colouring: (P2A) 1-layer coating system in RAL 5005 in accordance with LID 1608.03 Guide plate material: (K3I) Guide plate material: 1.4104/ 430F Hood extension material: (K5R) Hood extension material: 1.4404/316L Spindle material (K4Z) Spindle material: 1.4404/316L Pressure screw material: (K7T) 1.4104/ 430F + PTFE/ glass Wst stud screws Item 55 (L8K) Material of stud screws Pos. 55:1.4401/A4-70/SA-193+320 B8M Wst hexagonal nuts Item 56 (L9K) Material of hexagonal nuts Pos. 56:1.4401/A4-70/SA-194-8M Approvals: (M33) Proof of setting pressure test (TRB 513 4.2, TRD 504 3.3.4): EN 10204-3.2 (TÜV North) Material quality certificate for: (H01) Housing — position 1 with material quality certificate 3.1 in accordance with DIN EN 10204 Documentation: (H03) LESER CGA Certificate for Global Application Acceptance Test Certificate 3.1 in accordance with DIN EN 10204

Please Contact Us to Order to offer competitive prices and delivery time for Leser - 4415.7382 - H2 High performance safety valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
