BRAND | Leser |
Product | 4393.2882-90PSIG |
Description | SAFETY RELIEF VALVE |
Internal code | ONR4811418 |
Custom code | 84814010 |
Technical specification | Compact performance safety valve, type 439, for maximum tightness, closed spring cover, gas tight cap H2, for vapors, gases and liquids Technical specification: Order code output, line 1: K7TM33K4XH03P2AX00V61V70L44J23 Order code output, line 2: MB8H01 E body material: 1.4404/316L 1.4404/316L Total entry: (V61) NPT 1/2 external thread according to ASME B1.20.1 Total outlet: (V70) NPT 1/2 internal thread according to ASME B1.20.1 Nominal diameter inlet NPT 1/2 Nominal diameter outlet NPT 1/2 PN 250 pressure level inlet PN 160 pressure stage outlet d0 (ASME-DIN) [mm] 10.0 Outflow rate D/G: 0.45 Outflow rate F: 0.37 Response pressure: 90.00 Pressure unit: psi-g Response pressure [bar-g] 6.21 Response pressure in psi-g: 90.00 Cold set pressure [bar-g] 6.21 Cold setting pressure [psi-g] 90.07 Operating temperature: 105 Temperature unit: °C - Celsius Operating temperature [°C] 105.00 Operating temperature in °F: 221 Plate, metallic/Wst.: (L44) made of material 1.4404/316L Soft sealing plate: (J23) with FKM “L” soft seal (Viton, Fluorel, Technoflon) Spring material (X00) standard material Colouring: (P2A) 1-layer coating system in RAL 5005 in accordance with LID 1608.03 Approvals: (M33) Proof of setting pressure test (TRB 513 4.2, TRD 504 3.3.4): EN 10204-3.2 (TÜV North) Material quality certificate for: (H01) Housing — position 1 with material quality certificate 3.1 in accordance with DIN EN 10204 Documentation: (H03) LESER CGA Certificate for Global Application Acceptance Test Certificate 3.1 in accordance with DIN EN 10204 3. Identification, position: Set p: 90 psig Type and position of the 3rd identifier: (M16) World Shield marking 1st line |
Please Contact Us to Order to offer competitive prices and delivery time for Leser - 4393.2882-90PSIG SAFETY RELIEF VALVE number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
