BRAND | Brilex |
Product | 1005-9933-00 |
Description | Explosion Plate |
Internal code | ONR4193933 |
Custom code | 73269098 |
Technical specification | KE/586X920 Old Matnr.: 3870169 Type: Fl Bursting Disc With Counter-Fl Size: 586X920 Burst area: 5,350 cm2 Option: Default Material: 1.4301 Opening pressure: 0.100 bar Opening temperature: 20.0 °C Opening pressure tolerance +/-: 0.010 bar Vacuum resistance: 500 mmWC Minimum temperature ፦40.0 °C Maximum temperature: 120.0 °C Sealing material: EPDM foam tape Insulation Material Type: None Grounding flap: No |
Please Contact Us to Order to offer competitive prices and delivery time for Brilex - 1005-9933-00 Explosion Plate number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
