BRAND | Brilex |
Product | Type: GE DN 0200 mm / 1005-9680-00 |
Description | Safety plate |
Internal code | ONR3851473 |
Custom code | 73269098 |
Technical specification | Old Matnr.: 3869775 Product tariff number: 73269098 Total net weight: 6 kg Type: Curved rupture disc Size: DN 200 Burst area: 300 cm2 Option: Standard Material: 1.4301 Opening pressure: 0.100 bar Maximum temperature: 120.0 °C Sealing material: EPDM foam tape Insulation material type: None Grounding tab: No Opening temperature: 20.0 °C Opening pressure tolerance +/-: 0.010 bar Vacuum resistance: 5,000 mmWs Minimum temperature: -40.0 °C |
Please Contact Us to Order to offer competitive prices and delivery time for Brilex - Type: GE DN 0200 mm / 1005-9680-00 Safety plate number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
