BRAND | Itron |
Product | 233-12-8-62 |
Description | gas pressure regulator |
Internal code | ONR4504854 |
Custom code | 90322000 |
Technical specification | Item No. H4938 external pulse nominal size: DN 40 / Pressure rating: PN8 Connection type: flange according to DIN PN16 / Medium: inert gases according to DVGW G260 Installation length: 200 mm / Max. inlet pressure Pu: 8000 mbar Inlet pressure Pu min.: ** mbar / Outlet pressure Pds: 120 mbar Spring range: 70 - 140 mbar / Actuator: 12 inch Flow rate: ** Nm³/h / nozzle: 10 mm Valve disc angle: 10° Safety membrane: no SAV top shutdown: yes Pdso: 240 mbar SAV lower shutdown: no Spring range: 100 - 400 mbar SBV: yes SBV switching value: 30 mbar above Pds Flow direction/installation position: ** Fig. 2 Ambient temperature: -30°C to +60°C Paintwork: primed Screen in the entrance: yes |
Please Contact Us to Order to offer competitive prices and delivery time for Itron - 233-12-8-62 gas pressure regulator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
