BRAND | Itron |
Product | H3069 FLUXI 2000 G250 DN 80 |
Description | turbine wheel gas meter |
Internal code | ONR4858665 |
Technical specification | Nominal size: DN 80 Pressure stage: PN16 Connection: DIN flange overall length: 240 mm Material: ductile iron Gas type: according to DVGW worksheet G260 Reading direction: front reading Flow direction: freely selectable prepared for 2 diving pods (when fitted with diving sleeves, direction of flow please specify) Measurement range: 1:20 (max. possible measurement range 1:30 (ND) or 1:50 (HD) available for an additional charge) Pulse generator: 2x LF pulse generator + anti- Manipulation contact Pulse value: 1 cbm/pulse Plug: Binder male 2x Ermeto EO 6S PR sockets Type of lubrication: permanently lubricated (oil pump available at an additional cost) Operating temperature: -25°C to +55°C (after MID) Coating: water-based paint similar to RAL7035 PTB approval number DE-10-MI002-PTB001 Revision number: 2 No MID approved |
Please Contact Us to Order to offer competitive prices and delivery time for Itron - H3069 FLUXI 2000 G250 DN 80 turbine wheel gas meter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
