BRAND | RTK |
Product | MV 5211 (8102662/010) |
Description | motor control valve |
Internal code | ONR4916071 |
Technical specification | Original W.No. 13122647/010 in continuous form nominal size DN 25, nominal pressure PN 25 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 1.7 m³/h, stroke 25 mm Seat diameter 8 mm Surface treatment with zinc dust primer max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C Electrical actuator - type ReAct 30E-028 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor Adjustment speed 0.28 mm/s, stroke 25 mm Protection class IP 65 with pillars additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms |
Please Contact Us to Order to offer competitive prices and delivery time for RTK - MV 5211 (8102662/010) motor control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
