BRAND | RTK |
Product | MV5314 / DN150 |
Description | motor control valve |
Internal code | ONR4936812 |
Technical specification | Replacement for W.Nr. 14082568/010 MV 5314 Series in continuous form nominal size DN 150, nominal pressure PN 16 Housing material: cast steel EN-GP-240-GH Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 292 m³/h, stroke 50 mm Seat diameter 125 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 350 °C - valve without actuator - - welded valve seat |
Please Contact Us to Order to offer competitive prices and delivery time for RTK - MV5314 / DN150 motor control valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
