BRAND | Bifold |
Product | XS16-12-F4P4S2-77G-24D-30-AL-10X4-X8 |
Description | 3/2 way manifold control unit |
Internal code | ONR4585307 |
Custom code | 8481209090 |
Technical specification | SKU [13736] 3/4" NPT - Manifold - XS16-12 Mtr.: Bifold fluid power Type: XS16-12-F4P4S2-77G-24D-30-AL-10X4-X8 Material:SS316L Operating temperature range: -60°C to +40°C (@T6) XS16-12 Manifold control unit 1 “, 3/4 “NPT connection F4 filter regulator (manual drain) with pressure gauge P4 3/2-way SPR pneumatic valve (with pilot line stack capabilities), NC S2 FP03P - 3/2-way solenoid valve with manual override (M), NC 77G degree of protection: Cu-TR/IECEx, Ex d IIC Gb, Ex tb IIIC db T4/5/6 24D power supply 24V DC 30 Power consumption 3.0 watts AL seals Flourosilicone (-60°C to +90°C) 10X4 outlet pressure range 0.4 - 10 bar, filter element 40 - 50 μm X8 pressure gauge Ø50mm, 0-10bar, 1/8" NPT connection, glycerine filled gauge No exhaust flow control, exhaust breathers |
Please Contact Us to Order to offer competitive prices and delivery time for Bifold - XS16-12-F4P4S2-77G-24D-30-AL-10X4-X8 3/2 way manifold control unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
