| BRAND | Ascon |
| Product | X5-3150-0200 |
| Description | Thermoregulator |
| Internal code | ONR4709554 |
| Technical specification | X5-3150-0200 A.No.: G.No.: Front: 96 x 48 mm Supply voltage: 100... 240 V, 50/60 Hz Outputs: 4 relays (3 contacts, 1 changeover contact) 1 continuous output, configurable 0 (1)... 5V, 0... 10V, 0 (4)... 20mA or as logic output Serial port: RS485 slave + MP Interface protocol: Modbus/JBUS 2. Continuous output OP6: not included User manual: German/English Front color: dark gray input: * PT100; thermocouple type J, K, L, S, R, T, B, N; 0... 50 (300) mVDC, 0 (1)... 5VDC, 0... 10 VDC, 0 (4)... 20 mA, * 3 logic inputs * Feedback potentiometer for 3-point step control * Ext. Target value input Control: PID, heating or cooling, heating/cooling, 3-point stride Options: * RS485 (Modbus/JBus) slave and master, ProfiBus * 2nd continuous output OP6 * Frequency input * Programmer function |
Please Contact Us to Order to offer competitive prices and delivery time for Ascon - X5-3150-0200 Thermoregulator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
M1 series temperature controller
programmer controller
temperature controller
Transmitter, Controller
Process controller with setpoint programmer
REGULATOR
controller
Thermoregulator
Transmitter
Controller
Temperature controller features Setup Time 1 – 9999 s/min, Startup Wait Time 0-500 min Resistance thermometer - Pt100 input Thermocouple input - L, J, T, K, S, R, B, N, E, W3, W5 Auxiliary inputs - current transformer CT Mode of Operation – single or double acting PID loop, or On/Off with 3 alarms SPST relay - NO RS485 serial communications Auxiliary power supply 24 VDC, 30 mA max. Standards and Approvals - CE Listed, cULus
D351550000 Specification Alternate Part Number: D3-5155-0000 Manufacturer: ASCON Price Unit: Each Weight: 0.234kg (each) Rate code: 90321080 Generic code: ASCON RS485 CONTROLLER FOR DIN RAIL MOUNT WITH UNIVERSAL INPUT, 3 RELAYS, 1 SSR DRIVE AND
AC series multi-function programmable control system
Timer
Temperature Controller
regulator
MF series digital controller (unconfigured)
HEAT REGULATOR
Servo motor controller 48x96 mm
relay
