| BRAND | Pulsafeeder |
| Product | W092590-000 |
| Internal code | ONR479243 |
| Weight | 1 |
Please Contact Us to Order to offer competitive prices and delivery time for Pulsafeeder - W092590-000 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
PULSAtron Electronic Metering Pump, Series E PLUS max. Delivery: 0,25 GPH / 0,9 Liter/hour max. Pressure Head: 150psi (10 bar) 125 strokes/min. Liqiod End material: PVC head, TFE diaphragm, ceramic balls. Connection sizes: .25"I.D. x .38"O.D. / .25"ball Electrical: 115Volt, 50-60Hz, 4-20mA DC Direct, w/Stop, CE Approval Pump dimensions: 5" x 10" x 11" Boxed dimension: approx. 25 x 30 x 30 cm
(Pulsatron Metering Pump, Series E Plus, max. delivery: 5GPH, 120GPD (18,9 Liter/hour) max. working pressure: 100psi (7,0 bar) Manual ON/OFF, manual stroke control 0-100%, Pressure head glassfilled Polypropylene, Diaphragm PTFE, valve balls ceramic, .38 Dia. Tubing: .38"ID x .50"AD Electrical: 230Volt, 50-60 Hz, 1ph, 1,8m 3-wire)
Metering Pulsatron, Series E plus, Flow rate 2.3 liter / hr. (0.6 Gal./Std.), 125 strokes / min, max. output pressure 7,0 bar (100 psi). Dosing of PVC, PTFE valve seats, valve ball ceramic. External control, with stop Connections: 1/4 "ID x 3/8" OD hose connection. Drive: 230V, 50 / 60Hz. Piece Weight: 5.850 kg
Controller
Controller
MicroTrac cooling tower controller, Enclosure: NEMA 4X / IP65 • Dimensions: 6.44 x 3.2 in (163 x 82 mm) • Power Supply: 90 VAC / 50/60Hz / 5A; 250 VAC / 50/60Hz / 5A • Control Output: Line Voltage @240VA per Relay (2 Amps @ 120VAC) • Display: LCD • Set Point Range: 0 – 9,999 μS/cm • Set Point Differential (Hystersis): Fixed 5% below the set point
Flat Pulsar
Controller, Microtrac, 230 Volt for Water Treatment in cooling towers
OVERHAUL REPAIR KIT FOR MODEL- 7440 S-E GEAR-RATIO-10 PISTON -1.5 KOPKIT NO-KPFRABMACCC SERIAL V7712
Tag.No/SR No/Model No: MP-RW641-P062/N.A/18AM02 MP-RW641-P058/N.A/RPHB EM80-315/2 MP-RW641-P064/N.A/18AM02 PR Number: 11422830 RMC RTF-MEC 6 2000305469 RING, RETAINING Parts for gear pumps: Drawing & Item Number: GMH6-ACE-KLP/11 MANUFACTURER: PULSAFEEDER MANUFACTURER: ROPER PUMPS Old part number: 46710 Old part number: 46711
Diaphragm Metering Pump, Pulsa Series 880, Model # 880-S-E, Pump Head from StSt 316L, PTFE flat diaphragm, Viton O-ring seals, single ball valves, StSt 316L 6,73 Gal / hour (25,1 Liter / hour) 24,82 bar. Hydraulic Bypass Setting: 27 bar 1,125 Inch Piston, 0,5" NPT Connections, selfpriming Manual Stroke Length Control, Standard Motor (Factory Supplied), 1450 RPM, 0,5 HP, 230/400V, 3 ph, 50 Hz, Totally enclosed. Pump will be supplied with IEC 100 frame base Paint: Two Part Epoxy Green 880-S-E.. Unit weight: 40,000 kg
PUMP ASSAMBLY AND SPARE MANUAL FOR MODEL 25HJ S/N: -N626351-8 GEAR- 30 PISTON DIA -13 MM KOPKIT NO-N
1). 25HJ Pulsar - this pump requires 0.25 kW. The motor mounting is by B14 flange. We can accommodate 63, 71 and 80 frames.
PUMP ASSEMBLY AND SPARE MANUAL FOR MODEL 25HJ SER-V729784-22 GEAR- 20 PISTON DIA -10MM KOPKIT NO-NPK
1). 25HJ Pulsar - this pump requires 0.25 kW. The motor mounting is by B14 flange. We can accommodate 63, 71 and 80 frames. 2). The vacuum style leak detection is no longer available. This replacement pump will be complete with pressure type leak detection.
PUMP ASSEMBLY AND SPARE MANUAL FOR MODEL- 7440 SE GEAR-RATIO-10 PISTON -1.5 KOPKIT NO-KPFRABMACCC SE
1). 7440-S-E – this pump requires 1.1 kW to meet the maximum pressure rating. The motor mounting is by feet. I quoted the pump considering IEC 90 frame. If you need another size, please advise.
PUMP-AND-MOTOR ASSEMBLY – 30 GPH VS 200 PSIG 1,044,250.00 2,088,500.00 250,620.00 2,339,120.00
Pump-and-motor assembly Pulsafeeder metering pump model 880H-S-E, ½” X ½” female NPT port size, 316 stainless steel liquid end material, 1” dia. Teflon tube diaphragm, 1.5” piston diameter, 0.625” stroke length, 1 piece– ½” ball for each suction and discharge, capable of delivering 30 gph against 200 psig. Pump is directly coupled to a ¾-hp, 1750-rpm, 230/460-V, 3-phase, TEFC, 56-frame size, 60-Hz motor
PUMP-AND-MOTOR ASSEMBLY – 9.88 GPH VS 100 PSIG
Pump-and-motor assembly Pulsafeeder metering pump model 680-S-E, ½” X ½” female NPT port size, 316 stainless steel liquid end material, flat diaphragm, 1.125” piston diameter, 0.50” stroke length, 1 piece – ½” ball for each suction and discharge, capable of delivering 9.88 gph against 100 psig. Pump is directly coupled to a ¾-hp, 1750-rpm, 230/460-V, 3-phase, TEFC, 56-frame size, 60-Hz motor
RFN-7015.0 STAINLESS STEEL, FOR FEEDER A2-200X3.5,IDENT-NO. 1997416.
Locking Assembly
Rectangular duct fans
Rectangular duct fans
Rectangular duct fans
Speed Switch for CK series
Gasket, flat.312, .093, .016, Unit weight: 0,010 kg
UNION GASKET
