VNT-XSF-1020-520-010  - Brilex United States  Sales

BRAND Brilex
Product VNT-XSF-1020-520-010
Description Standard Explosion Vent Flat Rectangular
Internal code ONR499352
Weight 1
Technical specification Standard Explosion Vent Flat Rectangular Burst Pressure:0.10BarG +-25% @ 15-30 C To 1/3 SPECIFICATION Maximum Working Pressure:0.05BarG @ 15-30 C 1/3 SPECIFICATION Standard Explosion Vent Flat Rectangular Rectangular Explosion Vent External Size:1100 mm x 600 mm Internal Size: 1020 mm x 520 mm Vent Area: 0.52 Top Section Austenitic Stainless Steel Seal Membrane:Flouropolymer (Over 120C Aluminium) Bottom Section :Austentic Stainless Steel Burst Pressure:0.10 BarG +/ 25% Temperature Coefficient to drawing 00/00/08115 This explosion vent has a hole pattern designed to be installed into a frame supplied by Elfab.This assembly meets the requirements of directive 94/9/Ec(Atex) the user must coduct theus own risk assessment if they intend intend to use either a different hole pattern or a non Elfab supplied frame hole pattern to Elfab Standard

Please Contact Us to Order to offer competitive prices and delivery time for Brilex - VNT-XSF-1020-520-010 Standard Explosion Vent Flat Rectangular number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
