BRAND | Steimel |
Product | ASF2-20RD-170046R |
Description | pump |
Internal code | ONR4524623 |
Custom code | 84136039 |
Technical specification | A-SF2/20RD-VLFM, pump unit, 2-20 bar 1.5 kW, 1500, 230/400 V, 50 Hz, IP55, F, B5, IE3 1) 3 weeks length width height 623.00 210.00 240.00 millimetres millimetres millimetres Gear pump unit: SF 2/20 RD - VLFM Item no.: ASF2-20RD-170046R Dimension sheet: DPA052D-090LFM-R33 Spare parts list: DET052020RD-165R Suction and pressure connection: G 1/SAE 1 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh., helical gear Storage: multi-layer Shaft seal: radial shaft seal elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: 28.5/34.5 l/min. pressure: 5 bar Speed: 1450/1750 rpm. pressure relief valve Setting range: 2-20 bar Opening pressure: 8 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA040-1424-301 Bellhousing with foot: BLF052200110LA21 three-phase motor: LDM090-04-904 (Birkenbeul) Engine data: Power 1/2:1.5 /1.7 kW Speed 1/2:1500 /1800 rpm Voltage 1:230/400 volts at 50 Hz Voltage 2 265/460 volts at 60 Hz Efficiency class: IE3 Degree of protection: IP 55 Insulation class: F Design: B 5 with additional plate (without IE3) for: Voltage/frequency: 220-240/ 380-420 volts at 50/60 Hz 250-280/440-480 volts at 60 Hz Aggregate paint: primed Type plate: ETY924-D/E—PE02 |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF2-20RD-170046R pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
