BRAND | Steimel |
Product | T6-70P |
Description | gear pump |
Internal code | ONR4447420 |
Technical specification | Article - No. PT6-... Dimension sheet: DPA006-... Spare parts list (pump): DET006... Operating instructions DBA-ZP02 Suction and pressure connection Material design: Housing parts 1.4462 Drive and counter-pinion: 1.4462, straight toothed bearing journals and Cr2O3-coated packing area bushings: Bronze AW Clearing clearance: 0.1 mm Shaft seal: Buramex SF Bronze washers suction hole without Adhesive medium Viscosity: 50 - 5000 mPas temperature: 20 - 40°C Delivery data Q: 118 cm³/revolution p: max. 8 bar n: max. 500 rpm Rotation direction: right (with direction arrow) Trial run: yes, with HLPD 46 Pre-clean: rinse with white spirit painting without Silicone-free pump! The pump was tested with mineral oil and must be flushed on site before commissioning! Safety sign: EAY924-PL02 Nameplate: ETY924-D-E—PE01 |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - T6-70P gear pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
