BRAND | Zelisko |
Product | ZZUW1002-3_24KV |
Description | Voltage sensor |
Internal code | ONR4220910 |
Custom code | 85043121 |
Technical specification | Voltage sensor: UW1002-3_24KV Voltage sensor: UW1002-3 Insulation level: 24/50/125 kV Primary voltage: 16'000/V3 V Secondary voltage: 3.25/V3 V Measurement accuracy class: 0.5 Burden: 200kOhm 50pF Voltage factor: 1.2Un; 1.9 Un 8h Standard: IEC 61869-11 Operating temperature ፦25°C to +40°C Secondary connected load: 3-pole, 1.7m M8 <—> open end Compatible cable connector types: Nexans 480/484TB |
Please Contact Us to Order to offer competitive prices and delivery time for Zelisko - ZZUW1002-3_24KV Voltage sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
