BRAND | S+S REGELTECHNIK |
Product | 1301-2111-0530-220 |
Description | Pressure transmitter |
Internal code | ONR4776255 |
Technical specification | 24 V AC/ DC power supply with 0 -10 V output 7 - 33 V DC with output 4... 20 mA Response time 2 ms (typically 1 ms) characteristic curve ± 0.3% output 0 - 10 V Output signal 0 -10 V, 3-wire, (load > 10 kOhm) RL is burden-dependent Measuring range 0... 2.5 bar Measuring principle steel measuring cell Media temperature — 40... +135 °C Pressure connection G ½ "sealing at the back and pressure gauge (combination) with profile seal FPM spec. ww. G ¼ "DIN 3852 Relative pressure type Pressure measurement range 0... 2.5bar Overload < 6 bar: 5 x EW > 6 bar: 3 x EW (max 1500 bar) Burst pressure < 6 bar: 10 x EW > 6 bar: 6 x EW (max. 2500 bar) electrical connection 0.25 - 1.5 mm², via DIN EN 175301-803-A connector stainless steel housing, steel type 1.4305 plastic connector head, approx. 98 x 50 x 34 mm Installation directly on pressure line Stainless steel parts in contact with the measuring material, steel type 1.4305 Protection class III (according to EN 60 730) Protection class IP 65 (according to EN 60 529) * standards CE compliance, electromagnetic compatibility in accordance with EN 61326, according to EMC Directive 2014/ 30/ EU Drinking water approval in accordance with NSF/ANSI 61/372 UL certified according to ANSI/UL 61010-1 |
Please Contact Us to Order to offer competitive prices and delivery time for S+S REGELTECHNIK - 1301-2111-0530-220 Pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
