BRAND | RTK |
Product | Repl. WENr.16072135-020 |
Description | Pneumatic control valve - Model No. PV 6211 |
Internal code | ONR4247648 |
Custom code | 84818059 |
Technical specification | two-way design body size NPS 3", pressure class 150 ANSI body material carbon steel A 216-WCB Butt weld ends stem packing chevron rings PTFE/graphite characteristic: / flow direction: equal % / under seat parabolic plug, metal seat Cv value = 67 gpm, travel / stroke 1 1/4" seat diameter 2" surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to ANSI B16.34 max. allowed temperature TS 482 °F Pneumatic actuator - type ST 6135.B6-6G air supply max. 6 barg diaphragm area 280 cm² spring range 0.8..3.0 bar / max. stroke 35 mm safety position: spring to close (diverting valve: port A, mixing valve: port B) accessories: handwheel for manual operation - electropneumatic positioner, type TZID-C with HART (FKS-module) input signal 4..20 mA at 0 % input, valve closed - 3/2-way solenoid valve, G 1/4 power supply 230 V / 50 Hz - airfilter regulator with pressure gauge 10 bar, 1/4 NPT Ex ll 2Gc llC, -20 up to +70 °C (mounted on the positioner) |
Please Contact Us to Order to offer competitive prices and delivery time for RTK - Repl. WENr.16072135-020 Pneumatic control valve - Model No. PV 6211 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
