| BRAND | Berthold |
| Product | LB124 SCINT |
| Description | Contamination monitor |
| Internal code | ONR836373 |
| Weight | 1 |
| Custom code | 90301000 |
| Technical specification | 43727-10 124 LB SCINT portable alpha beta gamma contamination monitor with scintillation detector, flat scintillator, light detection with photomultiplier, active area 170cm², entrance window 2 x 0.4 mg/cm² metallized plastic, protective grille with transmission factor 80%, microprocessor electronics, digital/analog display, electroluminescent lighting, robust water-resistant housing, visual and audible alarm. Simultaneous separate measurement mode Alpha and beta gamma measurement Zero effect (alpha channel) < 0.1 cps Zero effect (beta gamma channel) < 10 cps Easy operation with just a few directly accessible function keys, selectable measurement modes, service functions, RS-232 interface. Nuclide list for over 50 nuclides with stored Calibration factors, expandable with user-defined nuclides. Data memory for 1000 measurement values with date and time Battery-powered or optional wall-mounted batteries or rechargeable with a plug-in power supply, > 50h operating time with alkaline batteries 7.8 Ah (without lighting), temperature range -20 to + 40° C Humidity 0% - 80% (without condensation) Protection class min. IP 53 |
Please Contact Us to Order to offer competitive prices and delivery time for Berthold - LB124 SCINT Contamination monitor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Detector Scintillitor counter
40416-03 LB4441-03-0a-Gd-E 50/50
(LB4441-03-0a-Gd-E 50/50Scintillation Counter: crystall NaI 50/50cable entry: sidecollimator axialstainless steel housingoperating temp.: -40°C ... +60°CATEX: II 2 G EEx de IIC T6, IP 65Customs tariff number: 90222900)
40421-02 LB4441-02-0A-GI-E 40/35
LB 444 density and concentration Scintillation counter: Crystal Nal 40/35 Cable connection: laterally collimator axially Stainless steel case Operating temp .: -40 ° C ... + 50 ° C ATEX: II 2 G Ex ib d IIC T6, IP 65 Customs tariff number: 90222900
LB 440 Level Gauge
40441-02 LB 440-02 obsolete/ replaced by LB 470-02-M
(LB 440-02 Level Evaluation Unit (Master) power supply: 115-125V AC housing: 19 inch module 21 TE, 3 HE protection class IP 20 display: 4-line LCD, illuminated menu controled calibration by softkeys automatic decay compensation self monitoring 1 analog output: 0/4-20 mA isolated 3 relay outputs for failure and alarm Customs tariff number: 90222900)
(LB 444 Dichte und Konzentration Dichtemessung, (Master) Netzversorgung: 230-250V AC
RF cable quad 6.0 m 4 x 6 m RF cable with N-male connector
Protective shell for measuring the level of the mold
processor
GAMMAcast detector
Operating manual
Measuring channel
Connection Cable for GAMMAcast Detectors
52592-100 CONNECTION CABLE FOR GAMMACAST DETECTORS
Connection Cable for GAMMAcast Detectors, 10 m Length with 3 m Heat Protection Hose, Straight PlugProtect Connection and Open Ends
Connection cable
Photomultiplier Socket with High Voltage Cascade and Voltage Divider
Connection Cable for GAMMAcast Detectors
LB-6639W BGO-15mID: 81637-11 PA-60030687
Basic module with the processor, power supply
19" rack, 3 HE with 7" colour display, master CPU for user interface, calibration, and data logging Ready for installation of up to 4 measuring channels Power supply 90-264 V AC
detector, type: nuclear USE: NUCLEAR TRASNMITTER
Card
density measurement device
