Buy 2140002702 / KP75-L/2-M12K M20-LH / M16-RH from HIMMEL in United States

BRAND	HIMMEL
Product	2140002702 / KP75-L/2-M12K M20-LH / M16-RH
Description	flat motor
Internal code	ONR5163047
Weight	58
Custom code	85015230
Technical specification	*Circular and face tolerances according to F = fine Dimension sheet:1NJ011634 K model series/design series:K75 Type/type:KP75-L/2-M12K - - Varnishing/painting - -:- Color/colour:RAL 5015 sky blue 2K/sky blue 2K-PUR - - Mechanical data - -:- K-size sheet/dimension sheet:1NJ011634 Design/mounting position:B3 K-mounting sides/ mounting sides:one-sided foot machining/one-sided foot machining Storage-DE/Bearing-DE:Double bearing Storage/bearing end:Einfachlagering/simple bearing Protection class:IP54 - - Output variant -:- Output variant/Output variant:Shaft with adapter/Shaft with parallel key W. diameter/shaft diameter [mm]:35 W. Length/shaft length [mm]:70 (free shaft end) Wave thread/shaft thread:M20-L.H. + M16-R.H. - - - - Electrical data - -:- Label/Approval\|Identification/Certification:CE Number of phases:3~ Rated output/ nominal power [kW]:13 Operating mode/Duty type:S1 Number of poles/poles:2 Nominal motor speed/Motor speed nom. [1/min; rpm]:5890 Rated voltage/nominal voltage [V]:400 Rated frequency/ Nominal frequency [Hz]:100 Rated current/Nominal current In [A]:22.4 Circuit/Wiring:S101 (Y) CosPhi/CosPHI:0.9 Insulation class:F Winding protector/ motor protector:PTC 160°C Supply type/power supply:FU mode/inverter duty Drive protection/motor protection (IEC60034-25):to be guaranteed by system managers/to be Guaranteed by System Manager Motor circuit diagram/Motor connection diagram:A0101000 Circuit diagram built-in 1/Con. diagram compon. 1:A01TP000 - - Electrical Connection/electrical connection- -:- K-elec. connection type/elec. connection mode:Terminal box/terminal box KK material/ terminal box material:aluminum/aluminum KK location/terminal box position:2BK KK screw connection/gland:(2x) -M25x1.5 + (1x) -M16x1.5 + (3x) -M12x1.5 - - Ventilation/Ventilation - -:- Ventilation type:E - Self-ventilation/self-ventilation - - - - - brake - - - - - - - - - - - - -:- Brake type:M12K [12Nm] (L8) Brake control voltage [V]:360-440 Wiring/Connection:separate/separate Brake 1 circuit diagram/Brake 1 connection diagram:A01BA000 - - - - load, forces - - - -:- Ambient temperature/ Ambient temperature /Ta [°C]:-20/+40 - - Rating plate/name plate - -:- K rating plate/name plate:adhesive label 90x60 /adhesive label 90x60 Rating plate logo/name plate logo: SKY - - List of goods/Harmonized codes - -: -

Discover the superior quality and performance of the HIMMEL 2140002702 / KP75-L/2-M12K M20-LH / M16-RH with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The 2140002702 / KP75-L/2-M12K M20-LH / M16-RH is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of 2140002702 / KP75-L/2-M12K M20-LH / M16-RH :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the 2140002702 / KP75-L/2-M12K M20-LH / M16-RH at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the 2140002702 / KP75-L/2-M12K M20-LH / M16-RH ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply HIMMEL products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy 2140002702 / KP75-L/2-M12K M20-LH / M16-RH by HIMMEL in United States?

You can purchase 2140002702 / KP75-L/2-M12K M20-LH / M16-RH by HIMMEL from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the 2140002702 / KP75-L/2-M12K M20-LH / M16-RH?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in United States?

While we are not the official distributor or seller of HIMMEL in United States, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access 2140002702 / KP75-L/2-M12K M20-LH / M16-RH catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 2140002702 / KP75-L/2-M12K M20-LH / M16-RH on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 2140002702 / KP75-L/2-M12K M20-LH / M16-RH?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
