| BRAND | Inor |
| Product | IPAQ C330 |
| Description | Transmitter |
| Internal code | ONR3320112 |
| Weight | 1 |
| Custom code | 90303320 |
| Technical specification | 70C3300012 with NFC technology Digital, PC-programmable, galv. isolated two-wire transmitter for terminal head mounting DIN B or larger wireless connectivity NFC® via capable device with INOR app Bluetooth® only together with ICON-BT input: Pt100/Pt1000/Ni100/Ni 1000 as 2-, 3-, 4-conductor Measuring range -200... +850 °C. Thermocouple type: B, C, D, E, J, K, N, R, S, T measuring range -200... +1500°C, temperature linear; Minimum measuring range: 20°C; Zero point setting: Over the entire measuring ranges; output: 4... 20 mA galvanically isolated 1.5 kV; supply voltage: 8... 36 VDC; Typical accuracy: max. ±0.08°K or ± 0.08% of the range; protection class: IP 65; Factory setting: Pt100, 3-L, 0... 100°C; |
Please Contact Us to Order to offer competitive prices and delivery time for Inor - IPAQ C330 Transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
