HT-100RS - Hitrol United States Sales

BRAND	Hitrol
Product	HT-100RS
Description	Magnetic Float Type Level Transmitter
Internal code	ONR3700895
Weight	1
Technical specification	Model : HT-100RS Type : Magnetic Float (Resolution : ±10mm) Installation : Top Ambient Temperature : -20 ~ +60 deg.C Fluid Temperature : Max. 80 deg.C Operating Pressure : Up to 10kg/cm2 Power Source : DC 24V Output Signal : DC 4...20mA (2-Wire) Enclosure : Weather Proof, IP65 Wetted Parts Material : 316LSS Housing Material : AL. Process Connection Size : ANSI 3" 150# RF Process Connection Material : 316LSS Measuring Length : L = 860mm, L1 = 100mm, L2 = 760mm Float Size / Material : 3" (ø73x105H) / 316LSS / Guide Pipe : ø21.7 Cable Entry : PF 3/4"(F) Medium : Water Reference Serial No. : 1207087001

Please Contact Us to Order to offer competitive prices and delivery time for Hitrol - HT-100RS Magnetic Float Type Level Transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
