2409E Type: IKZ 475.33 G S4 - Proxitron United States Sales

BRAND	Proxitron
Product	2409E Type: IKZ 475.33 G S4
Description	Inductive proximity switch
Internal code	ONR1377130
Weight	0.33
Custom code	85365019
Technical specification	Rated operating distance (Sn) 25 mm Output PNP n. o. Target steel St37, 1 mm thick 60 x 60 mm Location at metal flush mount ( free zone 5 mm ) Supply voltage (UB) 10 - 55 V DC Ripple voltage < 15 % Load current max. 0 - 400 mA Short-time load current 2 A / 10 ms 0,8 A / 100 ms Short circuit protection yes, pulsing No load current (I0) < 10 mA Voltage drop (Ud) 1,5 V / 50 mA Operating frequency (f) 100 Hz Switching hysteresis (H) 1 - 15 % Ambient temperature -25 ... +65 °C Protection class IP 67 Connection plug S4 Function display LED Housing material brass, nickel plated Further designs available Type With staggered frequency IKZ 475.33 G S4 F Art.-No: 2409F

Please Contact Us to Order to offer competitive prices and delivery time for Proxitron - 2409E Type: IKZ 475.33 G S4 Inductive proximity switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
