| BRAND | ProMinent |
| Product | GMXA1602PPB20000UA10000DE |
| Description | METERING PUMP |
| Internal code | ONR3436056 |
| Weight | 22.5 |
| Custom code | 84135040 |
| Technical specification | Pumpentyp : 1602 - 16bar; 02 l/h Anschl.6x4/SS6x5 Dosierkopfwerkstoff : PP - Polypropylen Dichtungswerkstoff : B - Standard Membr./Viton-B Dicht. Dosierkopfausführung : 2 - m.Entlüftung ; o.Ventilfeder Hydraulischer Anschluss : 0 - Standardanschluss Membranbruchmelder : 0 - ohne Ausführung : 0 - Gehäuse RAL5003/Haube RAL2003 Logo : 0 - mit PM-Logo Ausführung Leistungsteil : U - Universal 100-240V Kabel und Stecker : A - 2m Europa Relaisfunktion : 1 - Relais 3-pol. 230V, 8A Zubehör : 0 - ohne Zubehör Steuerungsvariante : 0 - Manual+Cont.m.PulseControl Dosierüberwachung : 0 - Dosierüberwachung dynamisch Fernstop (Pause) : 0 - ohne Bluetooth Sprache : DE - deutsch Zulassung : 01 - CE Dokumentationssprache : DE - deutsch Frequenz (Hz) : 50/60Hz Spannung (V) : 100-230V Leistung (W) : 25W Schutzart : IP66/NEMA4X Förderleistung (l/h) : 2.3l/h Gegendruck (bar) : 16bar |
Please Contact Us to Order to offer competitive prices and delivery time for ProMinent - GMXA1602PPB20000UA10000DE METERING PUMP number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Series: DLTA Delta Optodrive- Version A Pump Type: 1020 10bar, 19,1l / h con.12x9 / SS12x10 Dosing head: PV PVDF Seal material: T Standardmembr. / PTFE sealing. Dosing head: 3 m.Entlüftung, m.Ventilfeder Hydraulic Conn: 0 standard connection Diaphragm failure monitor: 0 None Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 0 without relay Accessories: 0 without accessories Control variant: M control module 4 -20 mA Security Options: 0 no access control Language: DE German Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50-60Hz Voltage: 100-240V Power: 73W Protection: IP65 Capacity: 19,1l / h Back pressure: 10bar
Series: DLTA Delta Optodrive- Version A Pump Type: 1612 16bar, 11,3l / h conn.8x5 / SS8x7 Dosing head: SS stainless steel Seal material: T Standardmembr. / PTFE sealing. Dosing head: 0 o.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Diaphragm failure monitor: 0 None Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 3 Fail safe appealing Accessories: 0 without accessories Control variant: 3 Manual + analog current PC + Security Options: 0 no access control Language: English EN Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50-60Hz Voltage: 100-240V Power: 73W Protection: IP65 Capacity: 11,3l / h Back pressure: 16bar
Plug valve Order number: 1018190
dosing container
Fasspumpe
type: D1C b Mounting: Wall version Power supply: 220 V, 50/60 Hz; IP 65 Dimensions (WxHxD): 200x200x76 mm
air driven double diaphragm pump
GALA0420TTT000UA100000 GALA GAMMA/L- PUMPE VERSION A
Pump type: 0420 4 bar, 20 l / h St.Anschl.12x9 Dosing head: TT PTFE + 25% carbon Seal material: T standard Membr./ PTFE sealing. Dosing head: 0 o.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 1 alarm sloping Accessories: 0 without accessories Control variant: 0 Manual + Cont. 1: 1 Security Options: 0 no access control Dosing monitoring: 0 dosing monitor dynamically Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50 / 60Hz Voltage: 100-230V Power: 23W Protection: IP65 Capacity: 17,1l / h Back pressure: 04bar
solenoid GAL_ Series: GALA gamma / L pump version A Pump type: 1000 10 bar, 0.7 l / h St.Anschl. 6x4 Dosing head: PV PVDF Seal material: T standard Membr./ PTFE sealing. Dosing head: 2 m.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 0 without relay Accessories: 4 multifunction valve + Accessories Control variant: 5 Timer + Cont. + P.C. + A.S. Security Options: 0 no access control Dosing monitoring: 0 dosing monitor dynamically Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50 / 60Hz Voltage: 100-230V Power: 17W Protection: IP65 Flow rate: 0,74l / h Back pressure: 10bar
solenoid GAL_ Series: GALA gamma / L pump version A Pump type 1005 10 bar, 5 l / h St.Anschl. 8x5 Dosing head: PP polypropylene Sealing material: E Standard Membr./ EPDM sealing. Dosing head: 2 m.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 0 without relay Accessories: 0 without accessories Control variant: 0 Manual + Cont. 1: 1 Security Options: 0 no access control Dosing monitoring: 0 dosing monitor dynamically Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50 / 60Hz Voltage: 100-230V Power: 17W Protection: IP65 Flow rate: 4.4 l / h Back pressure: 10bar
Magnetdosierpumpe GALa
Solenoid pump type 1005 10 bar, 5 l / h St.Anschl. 8x5 Dosing head: PV PVDF Seal material: T standard Membr./ PTFE sealing. Dosing head: 2 m.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 1 alarm sloping
DOSING PUMP HEAD, TYPE: DOS.H.ASS - 122.0x67.0, INTAKE AND DELIVERY with valves
MEHRSCH.MEMBR FUR S3CAH070580PVTS570W14100C
Mehrsch.Membr. S3_a d178x132 PTFE / EPDM Order number: 1029603
P/N: 792215 / MFV-DK Gr. III 1.5/10bar
Multi-function valve MFV-DK
792957 Ozon-Messzelle OZE 3-mA- 2 ppm
Sensor for measuring ozone in clear water
sensor OZE 3-mA-2ppm
