| BRAND | AC Motoren |
| Product | FCM 160 MA-2 B5 / PHE PTC |
| Description | AC asynchronous motor with cage rotor |
| Internal code | ONR4690111 |
| Weight | 120 |
| Custom code | 85015230 |
| Technical specification | Motor power: 11 KW/13.2 kW No. of motor poles: 2 Motor voltage: 3 x 400/690 V +- 10%, 50 Hz 3x 460/795 V +- 10%, 60 Hz Motor speed: 2945 min-1/50 Hz 3534 min-1/60 Hz Nominal motor current: 19.56/11.34 A Efficiency class: IE3 Efficiency: 91.2 - 91.2 - 89.4% at 4/4 - 3/2 - 2/4 cos phi: 0.89 Protection class: IP 55 Insulation class: F Weight: 113 kg Design: IM B5 (flange version) flange size: 350 x 300 x 250 mm Motor shaft: 42 m6 x 110 mm Terminal box position: top Coolant temperature: -20 to +40°C Installation height: < 1000 m and above sea level Colour: RAL 7030 stone grey cast iron housing |
Discover the superior quality and performance of the AC Motoren FCM 160 MA-2 B5 / PHE PTC with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FCM 160 MA-2 B5 / PHE PTC is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FCM 160 MA-2 B5 / PHE PTC :
At Onrion LLC , we offer the FCM 160 MA-2 B5 / PHE PTC at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the FCM 160 MA-2 B5 / PHE PTC ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply AC Motoren products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy FCM 160 MA-2 B5 / PHE PTC by AC Motoren in United States?
You can purchase FCM 160 MA-2 B5 / PHE PTC by AC Motoren from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the FCM 160 MA-2 B5 / PHE PTC?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of AC Motoren in United States?
While we are not the official distributor or seller of AC Motoren in United States, we source our products from reliable channels and offer you original AC Motoren equipment at competitive prices.
How can I access FCM 160 MA-2 B5 / PHE PTC catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for FCM 160 MA-2 B5 / PHE PTC on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for FCM 160 MA-2 B5 / PHE PTC?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
