BRAND	Baumüller
Product	DSD2-036SO44U-60-54-RBB-HPP-K-AN-O-000
Description	three-phase synchronous motor
Internal code	ONR4442494
Custom code	85015100
Technical specification	Article number 00469081 Dimension sheet: DSD2-036-MB-160125 torque M =1.1/0.9 Nm Rotational speed: n =3000/6000 rpm Power: P =350/570 W Current: I '1.5A voltage; Uzk=540 VDC Stopping torque: MO =1.2 Nm standstill current: 10 =2.05 A Heat class: F SI operating mode Ambient temperature: 40 x Temperature sensor: KTY 84-130 Temperature sensor connection: In signal connection Feedback: Sincos singleturn, SKS36 128 sinus/cosine periods per revolution holding brake: quiescent current actuated, 4 Nm, 24 VDC Connection, Type: Device sockets, angled, size 1 speedtec, Orientation: axial, rotatable Shaft end: @11h6x23, with feather key according to DIN 6885-1 Degree of protection: IP44

Please Contact Us to Order to offer competitive prices and delivery time for Baumüller - DSD2-036SO44U-60-54-RBB-HPP-K-AN-O-000 three-phase synchronous motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
