BRAND | Warex |
Product | DKZ110 DN 250 WX 2000 |
Description | butterfly valve |
Internal code | ONR4719234 |
Custom code | 84818085 |
Technical specification | Overall length 68 mm for clamping between flanges in accordance with EN 1092, PN 10 Silumin housing 1.4408 stainless steel flap disc 1.4057 stainless steel or higher quality shafts Shaft sealing using O-rings Brass shaft bearing - bushing Sealing collar made of black NBR replaceable in the housing with free shaft end, diameter 22 mm Connection in accordance with DIN/ISO 5211, F10 |
Please Contact Us to Order to offer competitive prices and delivery time for Warex - DKZ110 DN 250 WX 2000 butterfly valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
