| BRAND | Carlo Gavazzi |
| Product | CTD10V8005AXXX |
| Description | CURRENT TRANSFORMER 800; 5A |
| Internal code | ONR241800 |
| Weight | 1 |
| Technical specification | Primary brandCarlo Gavazzi Main functionCurrent Transformer (CT) Product series / family nameCTD series FunctionsAC solid-core current transformer Designsealable term. blk. cover Connection typedouble screw connections (up to 8 wires) Mounting modevertical mounting Degree of protectionIP20 Dimensions50x125mm window (with up to 10 isolated fixing screws) W106.7mm x H177.9mm x D40mm housing Primary current800 A Secondary current5 A Order code / Manufacturer SKUCTD10V8005AXXX Manufacturer product statusCommercialized Compliant with standard(s)EN 61869-2 ABS; self-extinguishing; UL 94 V-0 (housing) cURus CSA CE IP00 (without sealable terminal block covers) IP20 (with sealable terminal block covers + wire terminals) BenefitsBridging of current transformer output without changing the connection of the secondary so to avoid any output overvoltage during either the maintenance or the installation procedure. Easy output and earth connection. Screw terminals compatible with any kind of wire terminals. Accuracy class10VA (Class 0.5) Class 1 (Cl.1) at 15VA max. burden Class 3 (Cl.3) at 20VA max. burden |
Please Contact Us to Order to offer competitive prices and delivery time for Carlo Gavazzi - CTD10V8005AXXX CURRENT TRANSFORMER 800; 5A number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
