CPS-D-SW - Calectro United States Sales

BRAND	Calectro
Product	CPS-D-SW
Description	differential pressure switch
Internal code	ONR4737667
Technical specification	0 3500 Pa with display The CPS-D-SW pressure switch has a built-in differential pressure element, which ensures a high accuracy and linearity are temperature-compensated. that The differential pressure element has a high resolution, which means that the pressure value is in steps of max. 1 Pa About the The entire measurement range (0 to 3500 Pa) is presented. Supply voltage: 24V AC/DC +10% Power consumption: AC 80 mA, DC 50 mA Relay output: max. load 300 mA, 60V peak Averaged attenuation: 3, 10, or 20 seconds Measuring ranges, pressure: 0-3500 Pa Set value: Adjustable from 0-3400 Pa screw clamp - Cable diameter: 0.05-1.5 mm? - Type: pull sleeve Accuracy: Usually +1% of the measured pressure (@ >100 Pa). Display: Graphic LCD, backlit Ambient temperature: -20 to +50°C Cable inputs: 1xM16, 5-10 mm cable Dimensions (WxHxD): 78x90x40 mm Protection class: IP54

Please Contact Us to Order to offer competitive prices and delivery time for Calectro - CPS-D-SW differential pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
