CL-8-ATK - Carr Lane United States Sales

BRAND	Carr Lane
Product	CL-8-ATK
Description	Adjustable Torque Knob
Internal code	ONR1800132
Weight	0.1
Technical specification	FEATURES: Knurled knob that exerts positive, repeatable force. Clockwise, the knob declutches and turns freely when you reach the desired torque. Counterclockwise, the knob locks for positive retraction. Can be used as a controlled-torque nut, or as a thumb screw by installing a custom-made screw in the tapped hole. Made in USA. ADJUSTMENT: To set desired force, first remove the outer cover screw at the side of the knob, to expose the adjustment screw. Next, insert a hex wrench to turn the adjustment screw until desired torque is achieved. Reinstall the outer cover screw when finished. Torque can be adjusted from 3 to 6 inch-lbs, resulting in a contact force of 10 to 125 lbs, but these values are approximate. Force can vary +/- 30% depending on lubrication and other operating conditions. SIZES: One knob size, available with the following tapped-hole sizes: 1/4-20 M6 5/16-18 M8 3/8-16 M10 1/2-13 M12 MATERIAL: Body and knob > 12L14 steel, black oxide finish. Spring > 17-7PH stainless or music wire. DFARS and RoHS compliant.

Please Contact Us to Order to offer competitive prices and delivery time for Carr Lane - CL-8-ATK Adjustable Torque Knob number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
