Buy BF20-24/D09XA42-TOF-S/ESX010A9HA from Bauer in United States

BRAND	Bauer
Product	BF20-24/D09XA42-TOF-S/ESX010A9HA
Description	motor
Internal code	ONR4707083
Weight	48.5
Custom code	85015220
Technical specification	Flat gear motor with single-disc spring brake BF20-24/D09XA42-TOF-S/ESX010A9HA Motor power: 0.63/1.25 kW Speed of the AW: 46.5/93 r/min Torque: 129/128 Nm Operating factor fB: 3.3/3.3 Line-up: H1 Terminal box location: I/A Corrosion protection: standard Painting: RAL 7031 Dimensional image: BF20-BF20Z Catalogue: DG 07 Net weight per piece: approx. 49 kg Additional/special versions: Total coating thickness 40 μm Transmission design: Type: BF20 2-stage flat gearbox Version code number 24 with small flange on the front side (d: 200 mm) hollow shaft with keyhole (d: 30 mm) Total reduction i: 30.40 Additional/special versions: With mounting aid -hold-free as an accessory pack Motor design: Type: Three-phase rotor cage motor with pole shift D09XA42-TOF-S Rated speed: 1400/2800 r/min Voltage: 400 V Stator circuit: Y/Y frequency: 50 Hz Rated current: 1.85/3.0 A Power factor cos phi: 0.68/0.92 Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: Pole-switchable with two separate stator windings With built-in thermostats “opener” for shut-off in both windings in accordance with insulation class F according to additional connection diagram ZK010.1030-19. Type: ESX 010 A 9 HA single-disc spring brake Setting value: 10.0 Nm IP protection class according to EN 60 529: IP 65 coil voltage: 180 V Coil current: 0.17 A Additional measurement image: N-BR Cable design, solenoid coil connectors connected to rectifiers in the motor terminal box. Additional/special versions: With lockable hand ventilation. With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connection current: 0.12 A DC output: 180 V

Discover the superior quality and performance of the Bauer BF20-24/D09XA42-TOF-S/ESX010A9HA with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The BF20-24/D09XA42-TOF-S/ESX010A9HA is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of BF20-24/D09XA42-TOF-S/ESX010A9HA :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the BF20-24/D09XA42-TOF-S/ESX010A9HA at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the BF20-24/D09XA42-TOF-S/ESX010A9HA ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy BF20-24/D09XA42-TOF-S/ESX010A9HA by Bauer in United States?

You can purchase BF20-24/D09XA42-TOF-S/ESX010A9HA by Bauer from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the BF20-24/D09XA42-TOF-S/ESX010A9HA?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bauer in United States?

While we are not the official distributor or seller of Bauer in United States, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.

How can I access BF20-24/D09XA42-TOF-S/ESX010A9HA catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BF20-24/D09XA42-TOF-S/ESX010A9HA on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BF20-24/D09XA42-TOF-S/ESX010A9HA?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
