99-0430-135-04 - Binder United States Sales

BRAND	Binder
Product	99-0430-135-04
Internal code	ONR1295291
Weight	0.02
Technical specification	art no. 99 0430 135 04 Connector design Female angled connector Version Connector socket angled Connector locking system screw Termination screw clamp Degree of protection IP67 Cross-sectional area max. 0.75 mm² / AWG 18 Cable outlet 4.0-6.0 mm Twistability 90° (4 coding options) Temperature range from/to -40 °C / 85 °C Mechanical operation > 50 Mating cycles Weight (g) 23.50 Customs tariff number 85369010 Rated voltage 60 V Rated impulse voltage 1500 V Rated current (40 °C) 4.0 A Pollution degree 3 Overvoltage category II Insulating material group III EMC compliance unshielded

Please Contact Us to Order to offer competitive prices and delivery time for Binder - 99-0430-135-04 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
