924B DN80 - ABO Valve United States Sales

BRAND	ABO Valve
Product	924B DN80
Description	butterfly valve
Internal code	ONR4761999
Technical specification	For valves DN700 and greater – Double flange type and max working pressure 10bar Suitable for installation between flanges acc. ASME class 150 or EN1092-1 PN6/PN10/PN16 Design acc. to API 609 and EN 593 Face to face acc. to API 609 or EN 558-1 series 20 Leakage rate A acc. to EN 12266-1, testing ac. to EN 12266-1 or API 598 Design temperature range: -25°C to +125°C Max. working pressure: 16 bar For valves greater than DN250 – Horizontal installation recommended Body: Ductile Iron GGG40, 80um RAL2002 epoxy coated Disc: Stainless Steel 1.4408 (CF8M) Seat: EPDM Sealing rings: EPDM Stem and pivot: Stainless Steel 1.4021 bare shaft bare shaft without lever, gear or actuator

Please Contact Us to Order to offer competitive prices and delivery time for ABO Valve - 924B DN80 butterfly valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
