BRAND | Stahl |
Product | P/N: 150549, Type: 8570/15-406 |
Description | Flange socket |
Internal code | ONR4880628 |
Technical specification | Explosion-protected | Type : 8570/15-406 | AC rated operational voltage : 415 V | Frequency range : 50 - 60 Hz | Detailed number of poles : 4 P (3 P + PE) | Colour code : Red | Coding (clock hour position) : 6 | Auxiliary contacts available : No | Enclosure material : Polyamide | Application range (zones) : 1 , 2 , 21 , 22 | Gas explosion protection : II 2 G Ex db eb IIC T6 Gb | Dust explosion protection : II 2 D Ex tb IIIC T80 °C Db | Min. ambient temperature : -30 °C | Max. ambient temperature : +55 °C | Rated operational current : 16 A | Degree of protection (IP) : IP66 | Entries : - | Cable gland : - | Stopping plug : - |
Please Contact Us to Order to offer competitive prices and delivery time for Stahl - P/N: 150549, Type: 8570/15-406 Flange socket number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
