702.075 (54A625/B1P1) - Combimac United States Sales

BRAND	Combimac
Product	702.075 (54A625/B1P1)
Description	Centrifugal fan
Internal code	ONR4011747
Technical specification	direct driven, gastight, ATEX Colour outside: RAL 5017 blue Colour inside: 2-comp. black (epoxy) TECHNICAL INFORMATION FAN: - type = 54DZK625/S2P1 - part number = 702.075 - weight = 145 kg - medium temp. (max) = 60ºC - housing material = cast iron - impeller material = stainless steel AISI316 - graphic = 54A625/B1P1 - execution = εx II 3G/3G Ex h IIB T3 Gc/Gc - guideline = EN14986 - leakage test procedure = CN3022 TECHNICAL INFORMATION MOTOR: - voltage = 400V - 3 ph - power = 2,50 kW - frequency = 50 Hz - speed (synchr.) = 3000 rpm - frame = IEC 100L - ambient temp. (max) = 40ºC - insulation class = F - protection class = IP55 - type = εx II 2G Ex eb IIC T3 Gb - dimensions = D.003.670

Please Contact Us to Order to offer competitive prices and delivery time for Combimac - 702.075 (54A625/B1P1) Centrifugal fan number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
