BRAND | Warex |
Product | Type DKZ 110 APS DN 100 |
Description | Butterfly valve |
Internal code | ONR4687290 |
Technical specification | Construction length 39 mm to clamp between flanges in accordance with EN 1092, PN 10 Silumin housing 1.4408 stainless steel flap disc - with increased gap size - Stainless steel 1.4057 or higher quality shafts Shaft sealing with O-rings Brass shaft bearing - socket Black Buna CB sealing collar Replaceable in the housing Can be pneumatically clamped against the valve disc < APS > other attachments: Pneumatic rotary drive AT 60 DR double-acting Required control pressure 6.0 bar APS control 1002 1-channel control plan 0003475h 1x quick vent valve 1/4", with pressure regulator Throttle silencer 1/4" MS-Verz. 5/2 way solenoid valve function Norgren 2623077.3037 24 V DC, 1.6 W, IP 65 Namur version Limit switch box with 2 sensors P+F NBB2-V3-E2 3-wire, PNP, contact, 10-30 V DC, IP 67 built into the housing and wired to a terminal block To indicate the position to close (upper sensor) + Open (lower sensor) Characteristics: free-flowing, chemically neutral, Not prone to baking Working pressure: 3.0 bar Max. admissible Operating pressure: 4.0 bar (Ps) MAWP (Note: MAWP = Ausl. -Pressure) Operating temperature: 0 °C... + 60 °C (Ts) MAWT Surround. -Temperature: 0 °C... + 50 °C (Ta) Ex protection: no requirement evaluation of butterfly valves in accordance with DGRL 2014/68/EU, Diagram 7, certified module A2. The valves are subject to conformity assessment. Test pressure: design pressure x 1.1 bar for tightness |
Please Contact Us to Order to offer competitive prices and delivery time for Warex - Type DKZ 110 APS DN 100 Butterfly valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
