4834.7712 - Leser United States Sales

BRAND	Leser
Product	4834.7712
Description	Safety Valve
Internal code	ONR3354614
Weight	4
Custom code	84814010
Technical specification	Order code output, line 1: X00I17A17L79L86H04B53J22H85A85 Housing material: (H04) 1.4435/316L Nominal inlet DN 40 Nominal outlet DN 40 Pressure inlet PN 16 pressure stage outlet PN 16 d0 (ASME-DIN) [mm] 25.0 Flow rate D/G: 0.38 Flow rate F: 0.26 Connection inlet (L79) SO - Clamp connection/DIN 32676/ DIN 11850 Connection outlet (L86) SO - Clamp connection/DIN 32676/ DIN 11850 Connection outlet (L86) SO - Clamp connection/DIN 32676/ DIN 11850 Pipe Standard Inlet (H85) according to DIN 11850 & DIN 11866 series A Pipe Standard Outlet (A85) according to DIN 11850 & DIN 11866 series A Clamp size inlet/inner Ø 38.0 mm Clamp size inlet /outside Ø 50.5 mm Clamp size leakage, inner Ø 38.0 mm Clamp size leakage, outside Ø 50.5 mm Response pressure: 6.00 Printing unit: bar-g Response pressure [bar-g] 6.00 Response pressure in psi-g: 87.02 cold setting pressure [bar-g] 6.00 cold setting pressure [psi-g] 87,02 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Plate, soft sealing: (J22) with soft seal EPDM “D” Version according to reader serial number: 10373607 Clean Service Safety Valve, Type 483, for small and medium power, closed spring cap, gas-tight cap H2, for vapors, gases and liquids

Please Contact Us to Order to offer competitive prices and delivery time for Leser - 4834.7712 Safety Valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
