| BRAND | Leser |
| Product | 4332.4424 |
| Description | Modulate action safety valve |
| Internal code | ONR4540233 |
| Custom code | 84814010 |
| Technical specification | Type 433 normal SV, closed spring cap, gas-tight ventilation H4, for vapors, gases and liquids Technical specification: Order code output, line 1: K7TMB1K4XH03K3IP2AJ36X00L39H89 Order code output, line 2: H80H65H22L8JL64L44J23H01 Rules: CE/vdTÜV Housing material: (H22) Housing made of material 1.0619 (GP240GH) (with triple certification: WCB, WCC, 1.0619) Nominal size inlet NPS 1/2" Nominal diameter outlet NPS 1/2" d0 (ASME DIN) 12.0 mm Outflow rate D/G: 0.29 Flow-out figure F: 0.19 Flange pressure stage inlet (H65) 300 lbs according to ASME B 16.5 Flange pressure stage outlet (H80) 300 lbs according to ASME B 16.5 Flange sealing surface inlet: (H89) Serrated spiral finish (Ra = 3.2 - 6.3 µm) according to ASME B16.5 Flange sealing surface outlet: (L39) Serrated spiral finish (Ra = 3.2 - 6.3 µm) according to ASME B16.5 Response pressure: 20.00 Pressure unit: bar-g response pressure 20 Response pressure in psi-g: 290.08 Cold setting pressure [bar-g] 20.00 Cold setting pressure [psi-g] 290.08 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Plate, metallic/Wst.: (L44) made of material 1.4404/316L Plate, soft-sealing: (J23) with soft seal FKM “L” (Viton, Fluorel, Technoflon) Sealing ring material: (MB1) Sealing ring made of graphite/1.4401 Spring material (X00) standard material Spring hood material: (J36) 0.7043 (GGG 40.3) Guide disc material: (K3I) Guide disc material: 1.4104/430F Spindle material (K4X) Spindle material:1.4021 Compression screw material: (K7T) 1.4104/ 430F+ PTFE/ glass Ventilation/cap material: (K8W) Ventilation/ cap material: 0.7040/ 60-40-18 Stud screws Wst. Item 55 (L8J) Stud screw material pos. 55:1.7225/ SA-193 B7/SA-320 L7 Hexagon nuts Wst. Item 56 (L9J) Material hexagon nuts pos. 56:1.7225/SA-194 Gr.7/SA-320 7L Locking screw material: (MB5) Colorway: (P2A) 1-layer coating system in RAL 5005 according to LID 1608.03 Material quality certificate for: (H01) Enclosures — position 1 with material quality certificate 3.1 according to DIN EN 10204 Documentation: (H03) READER CGA Certificate for Global Application acceptance test certificate 3.1 according to DIN EN 10204 |
Please Contact Us to Order to offer competitive prices and delivery time for Leser - 4332.4424 Modulate action safety valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
