BRAND | Baumüller |
Product | P/N: 00455660, Type: DS D2-036MO44U-45-54-ROB-PPP-K-AN-0-000 |
Description | three-phase synchronous motor |
Internal code | ONR4518941 |
Technical specification | Dimension sheet: DSD2-036-MB-160125 Torque: M = 1.7/1.5 Nm Speed: n = 3000/4500 rpm Power: P = 530/71 0 W Current: l = 2.2/1.95 A Voltage: Uzk = 540 V DC Stopping torque: MO = 2 Nm Standstill current: 10 = 2.55 A Wirme Class: F Operating mode: 51 Cooling type: IC41 0 Temperature sensor: 1 X KTY 84-130 Temperature controller connection: In the encoder connection Rijckfijhrung: SINCOS singleturn, SKS36 128 sine/cosine periods per revolution Connection, type: device sockets size 1, M23 angled, Orientation: axial, rotatable Shaft end: G511 h6x23, with feather key according to DIN 6885-1 Degree of protection: IP44 Diescher: |
Please Contact Us to Order to offer competitive prices and delivery time for Baumüller - P/N: 00455660, Type: DS D2-036MO44U-45-54-ROB-PPP-K-AN-0-000 three-phase synchronous motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
