BRAND | Berthold |
Product | 38478-121 |
Internal code | ONR3998193 |
Custom code | 78060010 |
Technical specification | UniProbe LB 491 Density Evaluation Unit Scintillation counter: crystal NaI 50/50 Collimator for irradiation: axial Power supply 95 - 250 V, 50 - 60 Hz Menu controlled calibration via HART-communicator Automatic decay compensation Error indication Ambient temp: -40 to +50 - 1 analog output: 0/4 - 20 mA, isolated, passive, switchable to active - 1 digital-Input for hold-signal Relays: Max. 250VAC or 30VDC at max. 5A noninductive - 3 relays, alternative signals: hold, max / min alarm, detector temp., rad. interference - 1 failure relay 4 conduits radial 3/4" NPT Flame proof protection: ATEX II 2GD Ex d IIC T6 IP66 T 70°C flame proof protection FM/CSA: Class I, Division 1&2, Groups A, B, C, D Class II, Division 1&2, Groups E, F, G Protection: Nema 4X / IP 66 Housing: stainless steel with water cooling |
Please Contact Us to Order to offer competitive prices and delivery time for Berthold - 38478-121 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
