BRAND	Baelz
Product	373-E45-40-15-171-1 + MP373-E45-1051
Description	Electric linear actuator with synchronous motor
Internal code	ONR559902
Weight	1
Technical specification	Motorized hoist drive for control operation Positioning electronics for drive control for assembly on baelz control fittings DN 15….150 with thrust-dependent motor limit switches. 373-E45-40-15-S21-2EZ-Fg1-22mm-230 Thrust : 4000 N Actuating speed : 15 mm/min 50 Hz 18mm/min 60Hz Degree of protection: IP 65 Ambient conditions : max. -10°C…+50°C, 0…75% r. F. non-condensing with manual intervention Hood : sheet steel, yellow S21 for DN 15 - 125 : aluminum stand, coupling and fixing screws 2EZ-Fg1k : 2 add. Limit switch for position signaling and 1 remote transmitter 1 kΩ Stroke : 22mm electr. Connection : 3 x M20 x 1.5 Power supply : 230 V, 50/60 Hz + baelz MP373-E45-PEL-230-M Input/Output: 0…10V, 0(4)…20mA selectable Delivery condition: 0…10 V Ambient temperature: max. -10…+50°C Drive must be equipped with a 1kΩ transmitter 230V, 50/60Hz

Please Contact Us to Order to offer competitive prices and delivery time for Baelz - 373-E45-40-15-171-1 + MP373-E45-1051 Electric linear actuator with synchronous motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
