BRAND | Baelz |
Product | 342-055 + 373-E07-20-18-301 |
Description | D VALVE |
Internal code | ONR3901179 |
Technical specification | Ventil und Antrieb fertig montiert. Best.-Nr. 342-055 Dreiwege-Regelventil mit Kühlrohr u. Faltenbalg 5.3103, max. 350°C, Hub 12 mm; ohne Antrieb 342-BK-SS-DN 20-PN 16-Kvs 6,3 Gehäuse: GJS-400-18-LT - 5.3103 max. 350°C/11,2 bar - 50°C/16 bar Spindel-Ø 10 mm DN 20, PN 16, Kvs 6,3 Durchgangsweg : (A-AB) Kvso: 0,004% Eckweg : (B-AB) Kvso: 2% Durchflussmenge : ____ Druckabfall : ____ max. zul. Differenzdruck, Mischventile (2 Eingänge/1 Ausgang) 16 bar max. zul. Differenzdruck Umstellventile (1 Eingang/2 Ausgänge) 0,6 bar Best.-Nr. 373-E07-20-18-301 Motorhubantrieb 3-Punkt 2000 N; 18 mm/min 373-E07-20-18-S21-230 Hub max. 22 mm Einschließlich Ständer und Kupplung (S21) IP 42; 230 V, 50/60 Hz |
Please Contact Us to Order to offer competitive prices and delivery time for Baelz - 342-055 + 373-E07-20-18-301 D VALVE number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
