BRAND | Warex |
Product | WX2000 |
Description | butterfly valve |
Internal code | ONR4764799 |
Custom code | 84818085 |
Technical specification | Model DKD110 DN 100 Installation length 39 mm for clamping between flanges in accordance with EN 1092, PN 10 metallic sealing - lock-tight not pressure-tight in the passage!! Leakage 1-2% area equivalent 1.4408 stainless steel housing 1.4408 stainless steel flap disc Perfectly fitted into the housing 1.4057 stainless steel shafts or higher Shaft bearing in brass - socket Shaft sealing using O-rings The valve is equipped with the following special equipment: with built-in shaft extension, height 150 mm, for heat dissipation + Isoplan 750 flat seal; 2 mm thick other attachments: pneumatic rotary actuator AT 30 DR double acting required control pressure 6.0 bar 5/2-way solenoid valve function Norgren 2623077.3037 24 V DC, 1.6 W, IP 65 Namur version - without end position message - |
Please Contact Us to Order to offer competitive prices and delivery time for Warex - WX2000 butterfly valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
