2000.35.013 - Pixsys United States Sales

BRAND	Pixsys
Product	2000.35.013
Description	Signal converter Current transformer
Internal code	ONR537782
Weight	1
Technical specification	---- General Features ----- Container46.1 x 63 x 26.4 mm (excluding terminals) Loop Power supply (2-cable technology) operating range 11-30 Vdc 12... 35 Vdc for RS485 serial version Connection: Screw terminals: 5.08 mm MountingPredisposition for mounting on a DIN bar (horizontal/vertical) Ambient conditionsTemperature -40+85 °C, humidity 10.. 90 uR% Material: PBT, gray color with epoxy resin filling Weight: Around 72 g DIP-Switch2/8 poles CE regulations, EN 61000-6-4, EN 61000-6-2, EN 61010-1 --- Technical Data --- Type of Measure TRMS Resolution and accuracy 12 Bit - 0.5% F.S. Capacity50 Arms or 25 Arms configurable via Dip-Switch, bipolar (+/-50A dc or +/-25A dc) Output 4... 20 mA or 0... 10 Volt + RS485 Passband - 3dBdc or 20... 2000Hz Response speed1000 ms 3 Kv insulation on bare cable Overload 2 kA impulsive, 300 continuous Crest Factor2 Hysteresis on measurement value 0.15% F.S.

Please Contact Us to Order to offer competitive prices and delivery time for Pixsys - 2000.35.013 Signal converter Current transformer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
