1.65.1.220.500 DN 4" - Boll Kirch United States Sales

BRAND	Boll Kirch
Product	1.65.1.220.500 DN 4"
Description	filter
Internal code	ONR568253
Weight	1
Technical specification	Filter type: 1.65.1 Case size (G.Q): 220,500 Nominal connection size: DN 4" Connection flanges according to: ASME, 150 lbs, RF Dimension sheet: Z145616 --- OPERATING CONDITIONS --- Fluid to be filtered: water Fluid group in accordance with PED 97/23/EC: 2 Fluid type in accordance with PED 97/23/EC: liquid Max. flow rate: 66.00 m³/h Operating pressure: not specified Permissible operating pressure: 10.00 bar Operating temperature: not specified Zul. Operating temperature min: 0.00 °C Zul. Max. operating temperature: 60.00 °C --- CONSTRUCTION/APPROVAL --- Design and layout: PED97/23/EC AD-2000 : Art. 3, paragraph 3 Volume of the container: 26.00 liters Pressure test by: Boll & Kirch with certificate Material certificates: EN 10204/3.1 --- MATERIALS --- Filter housing made of: carbon steel Seal made from: Perbunan --- FILTER ELEMENTS --- Item type: reinforced basket screen element Material of the element: CrNi steel Fabric made from: 1.4401 Fabric number: 35 Filter fineness: 500 μm Screen area: 2060 cm² --- ACCESSORIES --- Other accessories: cover screws/nuts and sockets: Galvanised discs --- CORROSION PROTECTION --- Exterior base coat: 2K-Ep RAL 5005 Internal corrosion protection: SikaCor Zinc R/Sika Poxitar F --- IDENTIFICATION --- Operator/factory sign: English Filters without CE mark

Please Contact Us to Order to offer competitive prices and delivery time for Boll Kirch - 1.65.1.220.500 DN 4" filter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
