1823-20 - Dwyer United States Sales

BRAND	Dwyer
Product	1823-20
Description	Low Differential Pressure Switch
Internal code	ONR4262075
Technical specification	Operating Range 3 to 22" w.c. Approximate Deadband At minimum set point: 0.35 At maximum set point: 0.70 Service Air and non-combustible, compatible gases Temperature Limits -30 to 180°F (-34 to 82.2°C) Pressure Limits 10 psig (68.95 kPa) continuous, 25 psig (172.4 kPa) surge Switch Type Single-pole double-throw (SPDT) Repeatability ±2% Electrical Rating 15 A at 120 to 480 VAC, 60 Hz Resistive 1/8 HP at 125 VAC, 1/4 HP at 250 VAC, 60 Hz De-rate to 10 A for operation at high cycle rates

Please Contact Us to Order to offer competitive prices and delivery time for Dwyer - 1823-20 Low Differential Pressure Switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
