12.2036.3003 - Angst-Pfister United States Sales

BRAND	Angst-Pfister
Product	12.2036.3003
Internal code	ONR3341583
Weight	0.05
Technical specification	APSOvib Stop buffer F, medium D 20mm, H 24mm, G M6, L 20mm Material elastomer part:NR, black Material connecting piece:S235JR zinc-plated, chromated (CR VI free) Execution:DIN 95364, Type F medium Hardness:approx. 55 Shore A On request:soft hardness, approx. 40 Shore A: spring constant: x 0.5; compressive force: x 0.68 hard hardness, approx. 70 Shore A: spring constant: x 2.0; compressive force: x 1.4 Note:these stop buffers are also available in hardnesses approx. 40 Shore A (soft) and approx. 70 Shore A (hard). Tolerance:DIN 2768-c; DIN ISO 3302-1 M3; DIN ISO 4759-1 Class A Working temperature:from -30 to 80 °C EU guidelines:2002/95/EC (RoHS) Form:DIN 95364, type F Application:Parabolic stop buffers are especially suitable for use as emergency end stops thanks to their progressive spring characteristic. Note to hardness: Attention:Stop buffers may only be subjected to pressure loads.

Please Contact Us to Order to offer competitive prices and delivery time for Angst-Pfister - 12.2036.3003 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
